18K 24K
    Ph-V-Hz 1Ph-220V-240V~50Hz 1Ph-220V-240V~50Hz
T3 Capacity Btu/h 14200 17000
Capacity W 4162 4982
Rated power Input W 2000 2430
Rated current A 9.0 11.2
Max power Input W 2500 3300
Max current A 13.0 14.4
Indoor air flow m3/h 700 700
Indoor noise level           dB(A) 56 56
Outdoor noise level           dB(A) 63 61
Compressor Type    Rotary Rotary
  Brand    HIGHLY HIGHLY
Dimensions   (W x D x H)&Weight Dimension(W*D*H) mm 660×680×430 660×680×430
Packing   (W*D*H) mm 740×795×468 740×795×468
Net/Gross weight   Kg 52/56 56/60
Pressure High(DP) MPa 4.5 4.5
Low(SP) MPa 1.9 1.9
Refrigerant     R410A R410A
Ambient temperature   ℃ 21~52 21~52
Suitable area   m2 20~35 23~40
Power supply cord     2.5mm2 2.5mm2
Qty 40’HQ     222 222
